Water Transport in Copper Mine
Work with High Pressures and Extreme Ambient Temperature
Estudo de Caso Nº
68
Cliente
Zaldivar SPA Mine
Chile
|
2018
Condições de Trabalho
Pressure: 24 & 30 bar | Ambient temperature: 5° to 28°C / 41° to 82°F
Solução Pexgol
Pexgol 160 mm (6”), Class 15 | Pexgol 160 mm (6”), Class 19 | Pexgol 160 mm (6”), Class 24 | Pexgol 160 mm (6”), Class 30
Aplicação
Water transport
Comprimento
9500 m
Categorias
The Challenge
The mining company Zaldivar SPA (Barrick) needed to implement a line of drinking water from the storage pond to the camp sector, crossing the entire mining site. Two thirds of the layout required a pressure of 24 and 30 bar, using the minimum amount of joints possible and in the shortest time conceivable.
Pexgol Solution
It was decided to install 9500 m of Pexgol pipe due to its advantages:
- High pressure resistance (24 and 30 bar)
- Supply in long lengths (sections of up to 600 meters) minimizing assembly time and number of joints.
- Resistance to mechanical stresses due to pipe dragging in hard to reach areas.
The installation was simple, fast and safe. Without resources or special tools, shortening the known assembly program with HDPE pipes.
